| TLP test model | TDR(Time Domain Reflection) |
|
Pulse Voltage |
Max:+/-2000V(0.1V/step) |
|
Pulse Current |
Max.40A |
|
Pulse Width |
100ns |
|
Pulse rise time |
200ps/2ns/10ns/20ns/50ns |
|
TLP test model |
TDR(Time Domain Reflection) |
|
Pulse Voltage |
Terminal Open: +/-1000V(0.1V/step) 50Ω load：+/-500V(0.2V/step) |
|
Pulse Current |
Short:Max.20A, 50Ω load:Max. 10A |
|
Pulse Width |
1ns/2ns/3ns |
|
Pulse rise time |
200ps/2ns/10ns/20ns/50ns |
